Lots
Lot 1: ANDMAR Model YSG-1224 TS CNC Precision Hydraulic Surface Grinder. Year 2022
Maximum grinding length/width 700mm/300mm. Maximum longitudinal table travel 760mm.Maximum cross travel 360mm.Magnetic table size 600mm x 300mm. Feeds (Longitudinal) 1 - 25m/min. Hand feed per rev 60mm. (Cross) Intermittent feed 1-12mm/min. Continuous feed 460mm/min. Hand feed per rev 5mm.Spindle speeds 1455 rpm. Max grinding wheel dia.355mm.Grinding wheel bore 127mm. Complete with NC Control, coolant tank/filtration. Overall dimensions L x W x H 2500mm x 1900mm x 2300mm. Approximate weight 3200kg.
PLEASE NOTE DO TO ACCESS THIS ITEM CAN ONLY BE COLLECTED ON THE FOLLOWING DATES:- 28th,29th & 30th OCTOBER, 2025
Lot 2: JONES & SHIPMAN Model 1074 Universal Production Cylindrical Grinder. Year 1977
Maximum swing 254mm. Maximum distance between centres 457mm. Table traverse 76mm-4572mm/min. Table swivel included angle 20°. Machine entensively equipped with 3&4 jaw chucks. 6 x steadies. Magnetic Chuck. Internal attachment. Spare grinding wheel hubs.Grinding wheels. Wheel dresser.Coolant/Filtration Unit. Machine Serial No. BO 93174. Machine dimensions L x W x H 2000mm x 1200mm x 1750mm. Approximate weight 2500kg.
Lot 3: XYZ SM SLV3000 CNC Milling Machine with ProtoTrak SM Control.Retrofitted with New Control 2023
Table size 1457mm x 305mm.Spindle speeds (low) 70-460 rpm (high) 500-3600 rpm. Longitudinal travel 1016mm. Cross travel 406mm.Knee travel 406mm. Quill travel 127mm. Quill feeds 0.038/0.076/0.152mm/rev.Spindle motor 5HP. Spindle taper ISO40. Maximum troat depth 610mm. Maximum table load 550kg. Fitted with removable 205mm high riser block.Machine dimensions L x W x H 1900mm x 1950mm x 2550mm. Approximate weight 1850 kg
PLEASE NOTE DO TO ACCESS THIS ITEM CAN ONLY BE COLLECTED ON THE FOLLOWING DATES:- 28th,29th & 30th OCTOBER, 2025
Lot 4: HARRISON M390 x 1250mm Between Centres Gap Bed Centre Lathe. Year 2000
Swing over bed 390mm. Swing over cross slide 246mm. Swing in gap 585mm. Distance between centres 1250mm. Spindle bore 54mm. Spindle speeds 25-2000 rpm. Fitted with 240mm dia 3 jaw chuck. 355mm dia. faceplate. Fixed steady 160mm dia. capacity.Quick change toolpost. Coolant. SONY Digital Readout. Serial No.G70642. Machine dimensions L x W x H 2500mm x 1250mm x 1700mm. Approximate weight 2000 kg.
Lot 5: SUNNEN Model MBB-1660-CH Horizontal Precision Honing Machine
Minimum dia. 1.5mm. Maximum dia. 165mm. Min/Max stroke 0.3 - 400mm. with PF-150 Oil Filter. Large qty of Tooling/Accessories. Machine Serial No. 3W194603. Overall dimensions L x W x H 1200mm x 1250mm x 1650mm. Approximate weight 1000 kg.
Lot 6: BAILEIGH Model BS-250M Horizontal Bandsaw. Year 2021
Single Phase (240V). Blade size 2460mm x 27mm x 0.9mm. Capacity (Rectangular) 90° 260mm x 110mm. (Rounds) 90° 220mm dia. (Square) 90° 215mm x 215mm. Mitre cutting 0-60°. Variable blade speed 20-85m/min. Coolant pump. Machine Serial No.21085440. Machine dimensions 1500mm x 700mm x 900mm. Approximate weight 250 kg.
Lot 7: GUYSON Model Euro 2SF Shotblast Cabinet with Extraction Unit. Year 1998
Machine Serial No. 501879. Machine dimensions L x W x H 750mm x 600mm 1650mm x . Approximate weight 250 kg.
Lot 9: MICROTAP G2 Tapping Machine
Spindle B6. Collet change system SZSO. Spindle travel 65mm. Single Phase (240V). Machine Serial No.01772
